x402 v2 Payments 2026: Implementation and Settlement Checks

x402 payments are implemented by including payment requirements in an API's 402 response. Prepare Node.js and a test wallet. First, verify v2 signatures and settlement on Base Sepolia. Configure paid responses to be delivered only after settlement succeeds.

Amounts and chain information are based on the official x402, Base, and Circle documentation linked as sources.

Setup and installation

Prepare a development environment where you can modify the API, along with test wallets. The examples use Node.js 22 and x402 SDK 2.28.0. The installation structure follows the official seller guide.

1. Prepare an EVM wallet address to receive payments.
2. Prepare a separate test wallet for making payments.
3. Obtain Base Sepolia test USDC for the payment wallet.
4. Create the practice project with the commands below.
5. Save the TypeScript files that follow in the same folder.

mkdir x402-demo
cd x402-demo
npm init -y
npm pkg set type=module
npm install --save-exact [email protected] [email protected] @x402/[email protected] @x402/[email protected] @x402/[email protected] @x402/[email protected]
npm install --save-dev --save-exact typescript tsx @types/node @types/express

The receiving server does not need the receiving wallet's private key. Configure the payment private key to be read only by the client process. The wallet signing method follows the official buyer guide.

This example has been checked through type checking and a simulated payment flow. It has not been tested through a completed transfer on the actual testnet. Check the on-chain results yourself using the execution steps below.

×

Test duplicate-request recovery to ensure payment retries do not cause a second settlement.

Comparing x402 v1 and v2

When implementing v2, align both the headers and the body fields. Changing only the header names will leave the data structures incompatible. The following table is based on the official migration guide.

The location for delivering v1 payment requirements is specified in the HTTP v1 specification. The standard location in v2 is the PAYMENT-REQUIRED header. An implementation may also return a body, but process the requirements using the header.

The HTTP v2 specification describes the status code as follows.

The server indicates payment is required using the HTTP 402 "Payment Required" status code.

Source: x402 HTTP v2 specification

v2 payment headers contain Base64-encoded JSON. Base64 is not encryption. Use HTTPS for externally accessible services.

HTTP 402 requests and the payment sequence

This exercise uses the default authorization flow for the EVM exact scheme. exact is a scheme for paying a specified amount. The sequence follows the x402 v2 core specification.

1. The client requests a paid API without payment information.
2. The server returns HTTP 402 and PAYMENT-REQUIRED.
3. The client selects an allowed set of requirements from accepts.
4. The SDK signs a payment authorization matching the selected requirements.
5. The client retries the request with PAYMENT-SIGNATURE.
6. The server validates the authorization through the facilitator's /verify.
7. If verification passes, the server processes the resource.
8. The server requests settlement through /settle.
9. After settlement succeeds, it delivers the paid body and PAYMENT-RESPONSE.

This is not a fixed sequence shared by all payment schemes. v2 also defines flows with different settlement timing. The code below allows only the default authorization flow.

Roles of the Resource server and facilitator

The Resource server determines prices and conditions for accessing content. The Facilitator handles payment verification and settlement. This division of roles follows the official facilitator documentation.

/verify is a check that does not change on-chain state. Successful verification therefore does not mean funds have been received. The balance or authorization state may change even after verification.

Block the paid body if verification or settlement fails. Blocking access when success cannot be confirmed is called fail-closed behavior. This behavior can also be seen in the official Express implementation.

Comparing Base mainnet and testnet

Use only Base Sepolia for the first run. Circle states that testnet USDC has no monetary value. The addresses are based on Circle's list of USDC contracts.

Check the Chain ID and RPC in the Base network documentation. Even for the same wallet address, balances are separate on different chains. Do not record testnet success as actual revenue.

You can request test USDC from the Circle Testnet Faucet. Select Base Sepolia as the network. Enter the test payment wallet's address as the receiving address.

Implementing a paid API in Node.js

Attach paymentMiddleware before the paid route. The example below requires 0.001 USDC per call. The amount uses the example price from the official seller guide. (Verified value: 0.001 USDC per call · Source: docs.x402.org · Checked on 2026-10-28)

Server file

Save the following code as server.ts. The server accepts requests only on the local interface. It reads the receiving address from the PAY_TO environment variable.

import express from "express";
import { getAddress, zeroAddress } from "viem";
import { paymentMiddleware } from "@x402/express";
import { HTTPFacilitatorClient, x402ResourceServer } from "@x402/core/server";
import { ExactEvmScheme } from "@x402/evm/exact/server";

const payTo = getAddress(process.env.PAY_TO ?? "");
if (payTo === zeroAddress) throw new Error("Invalid payTo");
const network = "eip155:84532";
const resourceServer = new x402ResourceServer(
  new HTTPFacilitatorClient({ url: "https://x402.org/facilitator" }),
).register(network, new ExactEvmScheme());

const app = express();
app.use((_req, res, next) => {
  res.setHeader("Cache-Control", "private, no-store");
  next();
});
app.use(paymentMiddleware({
  "GET /paid-data": {
    accepts: [{ scheme: "exact", price: "$0.001", network, payTo }],
    description: "Sample paid JSON",
    mimeType: "application/json",
  },
}, resourceServer));
app.get("/paid-data", (_req, res) => {
  res.json({ content: "Paid sample content" });
});
app.listen(4021, "127.0.0.1");

https://x402.org/facilitator is the testing address in the official guide. This example uses it for Base Sepolia settlement. For choosing a production facilitator, see the mainnet steps in the seller guide.

Price calculation example

The example price is 1000 in USDC's smallest units. USDC has 6 decimal places. The SDK's price conversion is based on the EVM server implementation.

0.001 USDC × 10^6 = 1000 smallest units

price is an SDK configuration value. The actual v2 payment requirements carry amount. Compare integer amounts as strings or bigint.

Running the server and checking the 402 response

Run the server in the first Bash terminal. Enter a public receiving address, not a private key. Keep this terminal open while the server is running.

read -r -p '수취 지갑 주소: ' PAY_TO
export PAY_TO
npx tsx server.ts

Send a request without payment from a second terminal. The command below does not sign a payment. It prints the HTTP status and decoded payment requirements.

node --input-type=module <<'JS'
const response = await fetch("http://127.0.0.1:4021/paid-data");
const header = response.headers.get("PAYMENT-REQUIRED");
console.log(response.status);
console.log(header && JSON.parse(
  Buffer.from(header, "base64").toString("utf8")
));
JS

The expected response without payment is HTTP 402. Compare the printed requirements with the table above. If paid content is returned immediately, fix the route protection configuration first.

Selecting payment requirements and implementing the client

Restrict the client to signing only approved requirements. This example allows only a fixed price in Base Sepolia USDC. The payment option filter uses registerPolicy from the official x402Client implementation.

1. Save the code below as client.ts.
2. Also save check-transfer.ts from the next section.
3. Once both files are ready, proceed with the execution steps.

import { writeFile } from "node:fs/promises";
import { getAddress, zeroAddress, type Hex, type Hash } from "viem";
import { privateKeyToAccount } from "viem/accounts";
import { x402Client, wrapFetchWithPayment } from "@x402/fetch";
import { decodePaymentResponseHeader } from "@x402/core/http";
import { ExactEvmScheme } from "@x402/evm/exact/client";
import { checkTransfer } from "./check-transfer.js";

const key = process.env.EVM_PRIVATE_KEY ?? "";
if (!/^0x[0-9a-fA-F]{64}$/.test(key)) throw new Error("Invalid test key");
const signer = privateKeyToAccount(key as Hex);
const payTo = getAddress(process.env.PAY_TO ?? "");
if (payTo === zeroAddress) throw new Error("Invalid payTo");
const network = "eip155:84532";
const token = "0x036CbD53842c5426634e7929541eC2318f3dCF7e";
const client = new x402Client().register(network, new ExactEvmScheme(signer));
client.registerPolicy((version, options) => version === 2
  ? options.filter(r =>
      r.scheme === "exact" && r.network === network &&
      r.asset.toLowerCase() === token.toLowerCase() &&
      r.payTo.toLowerCase() === payTo.toLowerCase() && r.amount === "1000" &&
      (!r.extra?.assetTransferMethod || r.extra.assetTransferMethod === "eip3009") &&
      (!r.extra?.paymentFlow || r.extra.paymentFlow === "authorization"))
  : []);

const paidFetch = wrapFetchWithPayment(fetch, client);
const response = await paidFetch("http://127.0.0.1:4021/paid-data", {
  redirect: "error",
});
const raw = response.headers.get("PAYMENT-RESPONSE");
if (!raw) throw new Error(`No settlement receipt: HTTP ${response.status}`);
const settlement = decodePaymentResponseHeader(raw);
await writeFile("settlement.json", JSON.stringify(settlement, null, 2));
if (!response.ok || !settlement.success || settlement.network !== network) {
  throw new Error("Payment unresolved; inspect settlement.json before retrying");
}
const evidence = await checkTransfer(
  network, settlement.transaction as Hash, signer.address, payTo, 1000n,
);
await writeFile("transfer.json", JSON.stringify(evidence, null, 2));
console.log(await response.text());

wrapFetchWithPayment handles the 402 response and retries the request with a signature. Its usage follows the official fetch example. If no payment requirements are allowed, payment creation stops.

AI agents can also use this client. However, a per-call price limit is not a cumulative spending limit. Manage the budget for an agent's repeated calls separately.

Verifying USDC Transfer events

Check the USDC transfer logs using the transaction hash from the settlement result. A successful transaction status alone does not confirm the recipient. The Transfer fields follow the ERC-20 standard.

Verification requires the following items.

Save the code below as check-transfer.ts. The lookup uses viem's getTransactionReceipt. Event parsing is based on parseEventLogs.

import {
  createPublicClient, http, getAddress, parseEventLogs,
  erc20Abi, type Address, type Hash,
} from "viem";
import { base, baseSepolia } from "viem/chains";

const configs = {
  "eip155:84532": {
    chain: baseSepolia,
    rpc: "https://sepolia.base.org",
    token: "0x036CbD53842c5426634e7929541eC2318f3dCF7e",
  },
  "eip155:8453": {
    chain: base,
    rpc: "https://mainnet.base.org",
    token: "0x833589fCD6eDb6E08f4c7C32D4f71b54bdA02913",
  },
} as const;

export async function checkTransfer(
  network: keyof typeof configs, hash: Hash,
  payer: Address, payTo: Address, amount: bigint,
) {
  const cfg = configs[network];
  const rpc = createPublicClient({ chain: cfg.chain, transport: http(cfg.rpc) });
  if (await rpc.getChainId() !== cfg.chain.id) throw new Error("Wrong chain");
  const receipt = await rpc.getTransactionReceipt({ hash });
  if (receipt.status !== "success") throw new Error("Transaction failed");
  const logs = parseEventLogs({
    abi: erc20Abi,
    eventName: "Transfer",
    logs: receipt.logs.filter(
      log => getAddress(log.address) === getAddress(cfg.token),
    ),
    strict: true,
  });
  const transfer = logs.find(log =>
    getAddress(log.args.from) === getAddress(payer) &&
    getAddress(log.args.to) === getAddress(payTo) &&
    log.args.value === amount,
  );
  if (!transfer) throw new Error("Matching USDC Transfer not found");
  return {
    network, transaction: hash, logIndex: transfer.logIndex,
    blockHash: receipt.blockHash, blockNumber: receipt.blockNumber.toString(),
  };
}

This function confirms that a USDC transfer occurred in the transaction. Whether it belongs to a specific API order must be checked separately. On a production server, use the stored order requirements as the comparison values.

Do not trust a client-uploaded transfer.json as proof for granting access. This example's server uses the facilitator's verification and settlement results. If an independent lookup is a condition for granting access, it must run on the server.

A failed receipt lookup does not necessarily mean the payment failed. If an RPC error occurs, look up the stored transaction hash again. Set the number of additional confirmations and the response to chain reorganizations through your production policy.

Running a test payment and checking the results

After saving all the files, run the example with a test wallet. Type checking does not sign anything or transfer funds. The commands below use the TypeScript tools installed earlier.

1. Check the types with the following command.
2. Enter the same receiving address as the server in the second terminal.
3. Enter the test payment wallet's private key with input hidden.
4. Run the client once.
5. Check the saved settlement result and transfer log.

npx tsc --noEmit --strict --skipLibCheck --target ES2022 --module NodeNext --moduleResolution NodeNext server.ts client.ts check-transfer.ts
read -r -p '같은 수취 지갑 주소: ' PAY_TO
read -r -s -p '테스트 결제 지갑 개인키: ' EVM_PRIVATE_KEY
export PAY_TO EVM_PRIVATE_KEY
npx tsx client.ts
unset EVM_PRIVATE_KEY

Running the client again may create a new payment. This minimal example has no per-order duplicate prevention store. Add retries only after meeting the requirements in the next section.

Handling verification failure conditions

In failure tests, check that the paid body is not exposed. Checking only the HTTP status may miss cases where content is not blocked. Refer to the official Express middleware for the baseline behavior.

In the default authorization flow, the handler runs before settlement. A settlement failure does not roll back external operations. Start with queries that have no side effects, as in this example.

Sending emails or creating external orders requires a separate design. Record payment and task states together. Define which operations should run again after a failure to reduce duplicate work.

Lost responses after settlement and recovery through redelivery

Store payment completion and content delivery completion as separate states. Payment may finish while the response connection is lost. Handling this situation is covered in the Payment-Identifier extension documentation.

The property of not processing the same operation twice when it is requested again is called idempotency. payment-identifier provides a payment identifier for this purpose. Adding the identifier alone does not automatically complete the feature.

Comparing duplicate payments and redelivery

Preventing reuse of the same signature and preventing duplicate orders must be treated separately. EIP-3009 prevents reuse of an authorization nonce that has already been used. This behavior is defined in the ERC-3009 specification.

The following procedure is a design proposal for connecting the official extension to a production data store. It is not included in the minimal code above. Add persistent storage and concurrent request controls before using it in production.

1. Declare support for the payment-identifier extension on the server.
2. Keep the identifier for the logical request on the client.
3. Associate the identifier with the payer and request contents on the server.
4. Record the processing state atomically to prevent concurrent execution.
5. Save the transaction evidence and response result when settlement succeeds.
6. Return the stored result if the repeated request has the same authorization and contents.
7. If the settlement result is unclear, check the existing authorization first.

A payment identifier is not a password or access token. Do not return cached paid content to a request that merely knows the identifier. Also check whether it is being reused by another user or with a different request body.

Keep the chain, transaction hash, and log position together in production records. Link this record to the order to prevent reuse for other orders. A matching Transfer alone does not prove which order it belongs to.

Common payment implementation mistakes

Confusing version fields and success signals leads to incorrect payment decisions. Use the table below during deployment review. Version differences are based on the x402 migration guide.

USDC signature domain information also contains a version string. That value serves a different purpose from the x402 protocol version. See the ERC-3009 specification for the signing domain structure.

Security checks and trust boundaries for external services

Control payment success decisions on the server. Responses from an external facilitator are also an explicit trust dependency. The architecture, which also allows self-hosting, is explained in the facilitator documentation.

• Do not release content based on a client's success message.
• Compare the chain, token, amount, and recipient declared by the server.
• Do not log private keys or seed phrases.
• Exclude full authorization signatures from ordinary access logs as well.
• Limit payment header size and request processing time.
• Check that paid responses do not remain in shared caches.
• Store test keys and production keys in separate locations.
• Do not create an unpaid bypass when the facilitator fails.
• Actually test authorization expiration and duplicate requests.

The pinned dependencies in this exercise still have security warnings. npm audit reported a zod-related advisory. See the GitHub security advisory for details.

npm audit

Before deploying to production, check SDK compatibility with the patched version. Forcing a major version replacement may change behavior. Do not use this exercise as a deployment configuration that has passed security review.

Comparing a self-hosted server and Cloudflare Gateway

Using Cloudflare Gateway changes how the origin server verifies payments. The documentation dated September 30, 2026 specifies the use of x402 v2. The following comparison is based on the Cloudflare x402 documentation.

PAYMENT-CONTEXT is a header between the Gateway and the origin server. It is not a signature header for a regular x402 client. Follow the Cloudflare Payment validation documentation for origin verification.

Even when using the Gateway, simply decoding the JWT is not enough. Verify the signature using the keys specified in the documentation. Block paid content if the header is missing or verification fails.

Distinguishing actual usage from settlement records

The number of on-chain transfers alone cannot prove content consumption. Compile production metrics by linking settlement with response delivery. This is a design recommendation based on the payment flow and redelivery behavior.

Separate test requests from actual usage metrics. Mark retries for the same order separately as well. Do not describe transaction volume itself as API demand or a guarantee of revenue.

Steps for switching to Base mainnet

Review mainnet use after checking both successful and failed testnet paths. Changing the network string alone does not complete the switch. The baseline procedure follows the official seller guide.

1. Confirm that the selected facilitator supports Base mainnet.
2. Check /supported for v2, exact, and eip155:8453 support.
3. Configure the authentication and terms of use required by the provider.
4. Change the network on both the server and client.
5. Change the client's allowed USDC address to the mainnet address.
6. Recheck the amount in the 402 response against the actual receiving address.
7. Connect the duplicate request store and failure recovery procedures.
8. Complete security checks on production dependencies.
9. Verify the actual transfer and content delivery using the small amount you configured.

Multichain support does not mean every combination is supported. Check the support offered by both the SDK and the facilitator. Use the network and token support documentation as the reference.
